E0201 High Pressure Static Elimination Antistatic Ionizing Air Gun

Description

  • Model: E0201
  • Brand: Maxsharer
  • Delivery: 7-10 days
  • Warranty: 12 months
  • E0201 Ionizing Air Gun It was designed with handle to remove both static and dust, and it should be operated with E0401 High Voltage generator.and the ionizing air guns are used in industry, clean room and so on.



  • Features:

    1.static elimination
    2.dedust
    3.flexible operating
    4.with E0401 high voltage generator

    5.operate with compressed air

  • Specification



    Product Name Ionizing Air Gun
    Operating Voltage 4.6KV
    Current Consumption 200uA
    Operating Temperature -10~50℃
    Weight 0.55Kg
    HV Cable length 3 Meters
    Air pressure 5~7Kgf/cm㎡
    Air velocity >10m/sec





  • Decay Test Results
    Testing Conditions Test voltage: 5KV-500V Operating Voltage: 4.6KV Temperature:22℃
    Distance 30mm 90mm 150mm
    Decay Time Positive 0.1s 0.4s 0.7s
    Negative 0.1s 0.3s 0.8s
  • Application

    E0201 Ionizing Air Gun It was designed with handle to remove both static and dust, and it should be operated with E0401 High Voltage generator.and the ionizing air guns are used in industry, clean room and so on.

  • Package

    1pc into a inner box first, then 2pcs into a carton
